Stellar 85 RS

75 hp (Stage V) super low profile tractor with differentiated wheels and short wheel base. Generous driving platform and easy access on-board for maximum operating comfort.



Stellar 85 RS was developed to satisfy customers looking for a solid and efficient machine, with basic and essential set-up.

The oversized rear wheels guarantee traction also on difficult terrain, while the front wheels, with smaller diameter, ensure reduced turning radii.

Compact, agile and with low centre of gravity, Stellar 85 RS is the ideal tractor for working in orchards and vineyards, also on slopes, olive groves, greenhouses, canopy plantations or characterised by low foliage.

The new cab (optional) with an ultra-low profile and height off the ground of only 170 cm is available in two versions: “Compact Clima” with air conditioning and heating system or “Compact Pro” pressurised and Category 4 approved.

Transmission 16+16
POWER 75 hp
Driving position monodirectional
MIN. WIDTH 1338 mm

RS | Steering wheels

The oversized rear wheels, available in 20 or 24”, ensure high lifting capacity (2700 kg) and traction on any type of ground.

The OS-Frame and the steering acting on the front wheels ensure stability and adherence in any operating condition, even on slopes.

The standard manoeuvring brakes further reduce the turning radius for more agility between the rows.

Technical Data

Kohler KDI 2504 TCR – Stage V
Power (kW/HP) 55.4 / 75.3
Nominal speed (rpm) 2300
Number of cylinders 4 in-line / 16 valves
Displacement (cm3) 2482
Aspiration Turbo / Intercooler
Maximum torque (Nm/rpm) 300 / 1500
Type Differentiated wheels and short wheelbase with footstep driving position
Chassis Steering wheels
Driving position Monodirectional
Transmission 16 + 16
Synchronized reverser Yes
Electro-hydraulic power shuttle EasyDrive® n/a
Drive 4WD with front-wheel drive disengagement
Hydraulic system Dual circuit with independent pumps
Heat exchanger Yes
Joystick n/a
Rear lifting capacity (kg) 2700 (at the ball joint)
Front lift n/a
PTO rotation speed (rpm) 540 / 540E (optional: 540 / 1000)
PTO engagement control Electro-hydraulic positioned on the right mudguard
Service brakes Multi disc in oil bath, acting on rear wheels. Independent manoeuvring brakes acting on rear wheels
Cabin Optional. Ultra-low profile (minimum height 170 cm). Available versions: 'Compact Clima' with heating and air-conditioning system or 'Compact Pro' pressurised and Cat. 4 approved

n/a = not available

Running order weight: 2260 kg
Dimensioni-85 SDT step I_arco

Dimensions in millimeters (mm)

Running order weight: 2380 kg
Dimensioni-85-SDT-step-I_cabina

Dimensions in millimeters (mm)

Fighter-85-velocità

Tyres: 380/70 R20 – 320/70 R24 – 280/85 R24
Engine speed: 2300 rpm

Winning features.

  1. Kohler engine 75 hp 4-cylinder Turbo Intercooler.
  2. Generous footboard for greater operating comfort.
  3. Gearshift levers in forward position for much easier access on-board.
  4. PTO engagement control positioned on the right bumper.
  5. Levers for the operation of directional control valves all grouped on the right side.
  6. Lifting capacity of ball joints 2700 kg.
  7. LED work lights (in option), compact and trailing design to work in vegetation-rich environments.
  8. 24” rear wheels for maximum traction.
  9. ‘Compact Pro’ cab (optional) pressurised and Category 4 approved.
  10. Wide range of optional devices: rear lift with controlled position and draft, vertical tie rod and hydraulically-operated third point, hydraulic circuit with increased flow rate for lift and directional control valves, front bumper, adjustable steering wheel, Self Cleaning System™, cast iron flanges for 20” and 24” rear wheels.

Clean power.

Stellar 85 is equipped with a 75 hp 4-cylinder Turbo Intercooler engine – fully compliant with the Stage V emissions regulations – with particulate filter, that BCS Group worked on in collaboration with Kohler, their technological partner, for an advanced regeneration strategy guaranteeing maximum performance and reducing machine downtime to a minimum.

The engine revs are electronically adjusted quickly by a manual lever and a button that stores and retrieves the set speed.

Kohler-KDI-2504-TCR

New work station.

The driver’s seat was designed to combine ergonomics and comfort with close attention to the layout of the controls according to the logic applied to field tractors.

The new work station features all of the directional control valves and lift operating levers positioned on the right side, (also in the version with controlled draft), and the right bumper now has an electro-hydraulic control for PTO engagement.

Accordingly all of the controls for hydraulics can be easily used by the operator with his/her right hand, while the left hand stays firmly on the steering wheel.

Also, from the seat the operator has a complete and unobstructed view of the rear tool as well as the machine and wheel track.

Stellar-85-pto

Habitability and comfort.

The generous driving platform and the greater seat travel increase legroom and allow optimal use of the pedals.

Access to the driver’s seat has been made much easier by the forward position of the gearshift and reverser levers.

The cushioned and adjustable seat, based on the operator’s weight, and the height-adjustable steering wheel (in option) help alleviate some fatigue even after many hours of work.

Maximum protection!

‘Compact Pro’ cab | Stellar range

Ultra-low profile and Cat. 4 approved

The low chassis with height off the ground of only 170 cm makes use under the foliage, in pergola vineyards, canopy plantations and greenhouses extremely easy.

Pressurised and homologated in Category 4, isolates the operator from harmful inhalations during treatments with phytosanitary agents, making the work environment healthy and safe.

Find out more

Exclusive optional devices.

Self Cleaning System™

Self Cleaning System™

The SCS™ keeps the radiator and intake grilles of the engine bonnet constantly clean from dust and debris raised during work, avoiding dangerous overheating.

Find out more
Tecnologie-SCS-FER-card

Front bumper

Robust steel accessory that combines style and functionality by protecting the bonnet and radiator grille from impact.

Bumper-anteriore-60

Front ballasts

Ballast weighing a total of 150 kg, designed for mounting on both sides of the bonnet so as not to increase the size of the tractor.

Zavorre-anteriori

LED work lights

Two front LED lights, positioned under the bonnet grill, increase the lighted area favouring over-night work or in case of poor visibility.

Fari lavoro LED_FERRARI
